Model

Dell PowerEdge R240 Hot Plug Chassis /Technical Specification

Processor

1 processor from the following: Intel® Xeon® E-2100 product family, Intel Pentium®, Intel Core i3®, Intel Celeron®

Memory

4 x DDR4 DIMM slots, Supports UDIMM, up to 2666MT/s, 64GB Max. Supports registered ECC

Storage controllers

Internal controllers: PERC H730P, H330, HBA330 (non-RAID)
Software RAID: PERC S140/ External HBAs: 12Gbps SAS HBA (non-RAID)
Boot Optimized Storage Subsystem: 2x M.2 240GB (RAID 1 or No RAID), 1x M.2 240GB (No RAID only)

Drive bays

Up to 4 x 3.5 cabled SATA, SAS (optional) or SSD*
Up to 4 x 3.5 or 2.5 hot-plug SATA, SAS (optional) or SSD*
*available in the hot-plug configuration

Power supplies

Single 250W (Bronze) power supply

Dimensions

Form factor: Rack (1U)

Chassis width: 434.00mm (17.08 in)
Chassis depth: 595.63mm (23.45 in) (3.5” HHD config)
Note: These dimensions do not include: bezel, redundant PSU
Chassis weight: 12.2 kg (26.89 lb.)

Embedded management

iDRAC9 with Lifecycle Controller iDRAC Direct iDRAC RESTful API with Redfish

Bezel

Optional security bezel

OpenManage™ Software

OpenManage Enterprise/ OpenManage Power Center
OpenManage Essentials/ OpenManage Mobile (requires OpenManage Enterprise)

Integrations and connections

Integrations:
Microsoft® System Center
VMware® vCenter™
BMC Truesight (available from BMC)
Red Hat Ansible

Connections: Nagios Core & Nagios XI
Micro Focus Operations Manager i (OMi)
IBM Tivoli Netcool/OMNIbus

Tools

iDRAC Service Module
Dell EMC Server Update Utility OpenManage Server Administrator
Dell EMC Update Catalogs/ Dell EMC Repository Manager
Dell EMC RACADM CLI / Dell EMC System Update / IPMI Tool

Security

TPM 1.2/2.0 optional
Cryptographically signed firmware
Silicon Root of Trust

Secure Boot
System Lockdown (requires OpenManage Enterprise)
System Erase

I/O & Ports

Networking Options: 2 x 1GbE LOM Network Interface Controller (NIC) ports
Front ports: 1x USB 2.0, 1 x IDRAC micro USB 2.0 management port with x8 bandwith
Rear ports: 2 x USB 3.0, VGA, serial connector
2 x PCIe Gen 3.0 slots: • One x8 slot low-profile, half-length with x4 slot width
• One x16 slot low-profile/full-height, half-length

Supported operating systems

Certify XenServer
Citrix® XenServer®
Microsoft Windows Server® with Hyper-V
Red Hat® Enterprise Linux
Ubuntu Server

SUSE® Linux Enterprise Server
VMware® ESXi
For specifications and interoperability details,  see Dell.com/OSsupport.

OEM-ready version available

From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you./For more information, visit Dell.com/OEM.
