CBS250-8FP-E-2G-EU

Product order ID number

CBS250-8FP-E-2G-EU

Capacity in millions of packets per second (mpps) (64-byte packets)

14.88

Switching capacity in gigabits per second (Gbps)

20.0

RJ-45 ports

8 Gigabit Ethernet pOe+

Combo ports (RJ-45 + SFP)

2 Gigabit Ethernet combo

Flash

256 MB

CPU

800 MHz ARM

CPU memory

512 MB

Packet buffer

1.5 MB

Power dedicated to PoE

120W

Number of ports that support PoE

8

Unit dimensions
(W x H x D)

268 x 185 x 44 mm (10.56 x 7.28 x 1.73 in)

Unit weight

3.5 kg (7.72 lb)

Power

100 to 240V 50 to 60 Hz, internal

Certification

UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A

Operating temperature

23° to 122°F (-5° to 50°C)

Storage temperature

-13° to 158°F (-25° to 70°C)

Operating humidity

10% to 90%, relative, noncondensing

Storage humidity

10% to 90%, relative, noncondensing

Fan (number)

Fanless

MTBF at 25°C (hours)

1,706,649
